Smedent carbide burs FG, RA/CA carbide burr and HP Carbide burrs are adopted in original Austrian Tungsten carbide raw material for carbide burs head, Japan Stainless Steel for shank. We are pride that we are able to proceed our quality carbide burs,carbide cutters and CAD/CAM milling burs with the most advanced 6-axis CNC grinding machine with FANUC robot system and we proceed the carbide tip part with unique automatic welding technology, also we have strict QC light inspection system to check each piece burs welding spot,shank dimension, ensure each burs within the tolerance of International standard. Thus our Smedent carbide burs are well reputed by all partners at home and abroad.


OEM Service

Hot Product: FG2    FG4    RA4    RA6    FG557    FG330    FG245       Carbide burs 1171

Learn more about details, pls click the series number above.
Technical Parameters
Equipment & Package
CE,FDA,ISO Certificate
Round
dental lab burs US NO. ISO NO. 1/4 1/2 1 2 3 4 5 6 7 8
FG(19mm) 500314001001 005 006 008 010   014 016 018 021 023
FGSS(16.5mm) 500313001001 - 006 008 010 012 014 016 018 021 023
RA(22mm) 500204001001 005 006 008 010 012 014 016 018 021 023
FG SURG(25mm) 500316001001 - - 008 010 012 014 016 018 021 023
RA SURG(26mm) 640205001001 - - - 010 012 014 016 018 021 023
HP(44.5mm) 500104001001 005 006 008 010 012 014 016 018 021 023

Inverted Cone
Inverted Cone bur US NO. ISO NO. 33 1/2 34 35 36 37 38 39 40 41
FG(19mm) 500314010001 006 008 010 012 014 016 018 021 023
FGSS(16.5mm) 500313010001 006 008 010 - 014 - - - -
RA(22mm) 500204010001 006 008 010 012 014 016 018 021 023
HP(44.5mm) 500104010001 - 008 010 012 014 016 018 021 023

L Pear
330 dental burs US NO. ISO NO. 331L 332L 333L
FG(19mm) 500315238001 010 012 014
FGSS(16.5mm) 500313238001 - - -
RA(22mm) 500204238001 - - -

L Straight Flat End
dental burs manufacturer US NO. ISO NO. 57L 58L 59L 60L
FG(19mm) 500315109006 010 012 014 016
FGSS(16.5mm) 500313109006 - - - -
RA(22mm) 500204109006 - - - -
FG SURG(25mm) 500316109006 010 012 014 016
RA SURG(26mm) 500205109006 - - - -

Straight Flat End
Trimming Bur US NO. ISO NO. 56 57 58 59 60 61 62 63
FG(19mm) 500314107006 009 010 012 014 016 - - -
FGSS(16.5mm) 500313107006 009 010 - - - - - -
RA(22mm) 500204107006 - 010 012 014 016 018 - -
FG SURG(25mm) 500316107006 - 010 012 014 016 - - -
RA SURG(26mm) 500205107006 - - - - - - - -
HP(44.5mm) 500104007006 009 010 012 014 016 018 021 023

Straight End Cross-Cut
dental polishing burs US NO. ISO NO. 555 556 557 558 559 560 561 562 563
FG(19mm) 500314107007 008 009 010 012 014 016 - - -
FGSS(16.5mm) 500313107007 - 009 010 012 - - - - -
RA(22mm) 500204107007 - 009 010 012 014 016 018 021 023
FG SURG(25mm) 500316107007 008 009 010 012 014 016 - - -
RA SURG(26mm) 500205107007 - - 010 - - - - - -
HP(44.5mm) 500104107007 008 009 010 012 014 016 018 021 023

R Straight Dome End
dental burs for sale US NO. ISO NO. 1155 1156 1157 1158 1159 1160
FG(19mm) 500314137006 008 009 010 012 014 016
FGSS(16.5mm) 500313137006 008 009 010 012 - -
RA(22mm) 500204137006 - - - - - -
FG SURG(25mm) 500316137006 008 009 010 012 014 016
RA SURG(26mm) 500205137006 - - - - - -

Taper Flat End
Bullet Bur US NO. ISO NO. 168 169 170 171 172
FG(19mm) 500314168006 008 009 010 012 016
FGSS(16.5mm) 500313168006 - - 010 012 -
RA(22mm) 500204168006 - - - - -
FG SURG(25mm) 500316168006 008 009 010 012 016
RA SURG(26mm) 500205168006 - - - - -
HP(44.5mm) 500104168006 - 009 010 012 016

Pear
Zekrya US NO. ISO NO. 329 330 331 332 333
FG(19mm) 500314237001 006 008 010 012 014
FGSS(16.5mm) 500313237001 - 008 010 010 -
RA(22mm) 500204237001 - 008 - - -
FG SURG(25mm) 500316237001 006 008 010 012 014
RA SURG(26mm) 500205237001 - - - - -

L Taper Flat End
acrylic burs dental US NO. ISO NO. 1168 1169 1170 1171 1172
FG(21mm) 500314194006 008 009 010 012 016
FGSS(16.5mm) 500313194006 - - - - -
RA(22mm) 500204194006 - - - - -

L Straight Dome End Cross-Cut
fg carbide bur US NO. ISO NO. 1557L 1558L
FG(21mm) 500315139007 010 012
FGSS(16.5mm) 500313139007 - -
RA(22mm) 500204139007 - -

R Taper Dome End
Endo Z US NO. ISO NO. 1168 1169 1170 1171 1172
FG(19m) 500314194007 008 009 010 012 016
FGSS(16.5mm) 500313194007 - - - - -
RA(22mm) 500204194007 - - - - -

Wheel
chamfer bur dental US NO. ISO NO. 14
FG(19m) 500314042006 012
FGSS(16.5mm) 500313042006 -
RA(22mm) 500204042006 -

Amalgam Prep
Invert Taper bur US NO. ISO NO. 245 246
FG(19m) 500314233006 009 012
FGSS(16.5mm) 500313233006 - -
RA(22mm) 500204233006 - -

End Cutting
Needle bur US NO. ISO NO. 955 956 957 958
FG(19m) 500314150001 008 009 010 012
FGSS(16.5mm) 500313150001 - - - -
RA(22mm) 500204150001 - - - -

L Straight Flat End Cross-Cut
Flat Fissure bur US NO. ISO NO. 556L 557L 558L 559L 560L
FG(21mm) 500315109007 009 010 012 014 016
FGSS(16.5mm) 500313109007 - - - - -
RA(22mm) 500204109007 - - - - -
FG SURG(25mm) 500316109007 - 010 012 014 016
RA SURG(26mm) 500205109007 - 010 - - -

R Straight Dome End Cross-End
Esthetic Finishing Bur US NO. ISO NO. 1555 1556 1557 1558 1559 1560
FG(19mm) 500314137007 008 009 010 012 014 016
FGSS(16.5mm) 500313137007 - - - - - -
RA(22mm) 500204137007 - - - - - -
FG SURG(25mm) 500316137007 008 009 010 012 014 016
RA SURG(26mm) 500205137007 - - - - - -
HP(44.5mm) 500104137007 - - - 012 - -

Taper Flat End Cross-Cut
EGG bur US NO. ISO NO. 698 699 700 701 702 703 704
FG(19mm) 500314168007 008 009 010 012 016 - -
FGSS(16.5mm) 500313168007 008 009 010 012 - - -
RA(22mm) 500204168007 - 009 010 012 016 021 023
FG SURG(25mm) 500316168007 008 009 010 012 016 - -
RA SURG(26mm) 500205168007 - - - - 016 - -
HP(44.5mm) 500104168007 - 009 010 012 016 021 023

L Taper Flat End Cross-Cut
Fissure Bur US NO. ISO NO. 699L 700L 701L 702L 703L
FG(21mm) 500315170007 090 010 012 016 -
FGSS(16.5mm) 500313170007 - - - - -
RA SURG(22mm) 500204170007 - - - - -
HP(44.5mm) 500104170007 009 010 012 016 021

R Taper Flat End Cross-Cut
dental surgical burs US NO. ISO NO. 1701 1702
FG(19mm) 500314194007 012 016
FGSS(16.5mm) 500313194007 - -
RA(22mm) 500204194007 - -
FG SURG(25mm) 500316194007 012 016
RA SURG(26mm) 500205194007 - -

Package
  • diamond bur distribute1pc per bag
  • diamond burs manufacturer1pc per bag
  • diamond burs wholesale1pc per blister
  • round bur companies1pc per blister
  • Ceramic BurFG Blister Package of 10
  • Endo ZFG Burs Blister Pakcage of 5
  • Orthodontic burFG Burs Metal Package of 5
  • fg dentalFG Burs Metal Package of 10
  • dental bur manufacturerFG Burs Plastic Box of 4
  • fg burs manufacturerFG Burs Plastic Box of 10
  • fg burs supplierFG L Plastic Package of 6
  • Trimming BurFG Plastic Box Package of 6
  • surgical burs dentalHP Burs Blister Package of 5
  • fg carbide burHP Burs Plastic Box Package of 6
  • Orthodontic buHP Burs Single Package
  • Trimming BurHP Plastic Box of 7pcs
  •
  •
